Triple filtration system for dishwashers

Summer in Boise and its surrounding areas like Meridian, Nampa, and Caldwell can be a delightful time for relaxation and enjoyment. At Appliances 4 Less Boise, we believe your home appliances can play a significant role in simplifying your summer activities. Here’s how you can leverage these tools to enhance your summer experience, even with appliances that are open box, scratch, and dented.

When the dishes are taken out of the dishwasher, there are fine shredded vegetable residues, or a faint peculiar smell from the bottom of the machine. Behind these troubles is an exquisite system inside the dishwasher working silently. Triple filtration system is the key to solve these problems. This system, like the kidney of a dishwasher, silently undertakes the important task of circulating purification, protecting the core and ensuring the cleaning effect. It is not only the embodiment of technological progress, but also the key design to solve the problem of food residue disposal.

(1)、Why does the dishwasher need a filter system?

Dishwashers need a filtration system, which stems from its unique working principle. It does not simply spray out the water directly, but reuses the water many times through the circulating pump. Without a filtration system, food scraps can:

1. Blocking the spray hole, resulting in uneven water flow.

2. Wear water pump and motor components.

3. Reattach to the surface of the tableware.

4. Accumulation in sewers causing blockage.

Early dishwashers used a straight-row design to flush all residue directly into the sewer. This method is not only easy to plug the pipeline, but also a waste of water resources. The triple filtration system of modern dishwashers has gradually matured under these 1 backgrounds. It solves the core problem of food residue processing by combining physical interception 1 intelligent processing.

(2)、The first layer: coarse filter screen

The coarse filter at the bottom of the dishwasher is the 1 line of defense. It is usually made of stainless steel and has a large mesh (about 2-3mm aperture).

1. main functions

Intercept larger food debris, such as rice grains, leaves, bone fragments and other visible particles.

2. attention

This component requires regular maintenance by the user and is recommended to be cleaned once a month. When cleaning, just lift it up and gently scrub it with warm water and a soft brush. Keep the coarse filter clean, can make the water flow more smoothly, improve the cleaning efficiency.

(3)、The second layer: fine filter screen

The fine filter is located below the coarse filter, usually made of finer stainless steel or food-grade plastic, and the mesh is very small (about 0.5mm aperture).

1. main functions

Capture tiny particles, such as coffee grounds, spices, fine food fiber, etc.

2. tips:

①. This layer is the core of the filtration system and ensures that the circulating water is sufficiently purified before re-entering the sprinkler system. In most modern dishwashers, more than 90% of the solid residue is trapped in this layer.

②. The design of the fine filter takes into account the self-cleaning function-in the drainage stage, the special water flow path will wash the surface of the filter screen and take away some attachments.

(4)、Third layer: residue treatment device

This is the last processing link of the system. Different brands and models have different design schemes:

1. microfiltration device

In some models, this is a finer filter layer that deals specifically with the tiny residues of grease and proteins.

2. slagging system

Mid-to high-end models are usually equipped with more advanced treatment methods, such as food waste grinders or forced drainage systems. These devices can grind the accumulated residue to a very fine state and then wash it away with the drainage, greatly reducing the need for manual cleaning.

This design not only reduces the maintenance burden of the user, but also reduces the generation of peculiar smell-the residue will not stay in the machine for a long time.

(5)、System collaboration workflow

The triple system forms a complete filter chain at work:

1. Ffushing stage

The water containing the residue flows to the bottom filtration system.

2. first Interception

Coarse strainer retains large pieces of residue.

3. the second filtration

The fine filter catches tiny particles.

4. final treatment

The third layer device handles grease and extremely fine impurities, or carries out crushing discharge.

5. the water cycle

The cleaned water is pumped back to the spray system to continue flushing.

The whole process is repeated multiple times in each wash to ensure that the water is always sufficiently clean.

(5)、The deep value of triple filtration system

The benefits of this system go far beyond the cleaner dishes:

1. protect the machine

Prevent debris from damaging precision pumps and spray arms and extend the life of core components.

2. guarantee washing power

Ensure that the circulating water is clean, avoid secondary pollution, and let the sprayed water column always be strong and clear.

3. energy saving and water saving

Recycling of clean water reduces the energy consumption of heating new water.

4. maintenance of hygiene

Eliminate residue retention corruption, to avoid the machine to become a hotbed of bacteria and odor.

(6)、Maintenance suggestions

To ensure that the filtration system works effectively for a long time, you can pay attention to the following points:

1. monthly inspection

Remove all filter modules and clean them with warm water and neutral detergent.

2. avoid scratching hard objects

Do not use hard tools such as steel wire balls to clean the filter.

3. pretreatment of tableware

Pour off large pieces of food residue before putting them in the dishwasher.

4. observe drainage

If it is found that the drainage is not smooth, first check whether the filter system is blocked.

Good maintenance habits can not only improve the cleaning effect, but also extend the service life of the dishwasher. Data shows that dishwashers that regularly clean the filter system have a failure rate that is more than 40% lower than those that have never been cleaned.

ConclusionFrom the initial interception of the coarse filter screen to the precise filtration of the fine filter screen to the final decomposition of the residue treatment device, the dishwasher’s triple filtration system demonstrates the silent but efficient coordination of the 1 field. This system not only solves the problem of food residue treatment, but also reflects the environmental protection concept of modern household appliances through the use of recycled water.
